FLIR IM75 Insulation & DMM Combo with METERLiNK®
The FLIR IM75 is both an advanced multifunction digital multimeter and premier handheld insulation tester for installation, troubleshooting and maintenance professionals. The IM75 includes several specialty insulation modes including: Polarization Index, Dielectric Absorption and Earth Bond Resistance. Insulation tests can be performed instantly, continuously and over a timed duration for in-depth assessment.
IM75 Insulation & DMM Combo Specifications
| Technical Summary | Max Range | Basic Accuracy |
| Insulation Resistance | 4M to 20GΩ | ±1.5% |
| Insulation Test Voltages | 50, 100, 250, 500 and 1000V | ±3.0% |
| DC Voltage | 1000.0V | ±0.1% |
| AC Voltage | 1000.0 V | ±1.5% |
| VFD AC Voltage | 1000.0V | ±1.5% |
| Earth Bond Resistance | 40Ω to 40KΩ | ±1.5% |
| Capacitance | 10 mF | ±1.2% |
| Frequency (ACV) | 40kHz | +/- 5 digits |
| Diode Test | 2V | ±0.5% |
| Continuity | 400.0Ω | ±0.5% |
| General Information | ||
|---|---|---|
| IP Rating, Drop Test | IP 54, 2m (6.6’) | |
| Category Rating | CAT III-1000V, CAT IV-600V | |
| Bluetooth Range | 10m (32’) | |
| Battery Type | 6 x AAA | |
| Memory | 99 internal storage locations | |
| Operating Temperature | 32 to 122°F (0 to 50°C) | |
| Warranty | Limited Lifetime* | |
* When registered within 60 days of purchase.
FLIR IM75 Insulation & DMM Combo Related Accessories
 | TA10 Protective case for DM9x and IM7x Series |
 | TA50 Magnetic Hanging Strap |
 | TA70 CAT IV Insulated Alligator Clips |
 | TA80 CAT IV Silicone Test Leads |
